Cable Management, ICC Ladder Racks, Cable Tray, Wire Trays, Cable trays, Raceway Systems, Ladder racks, raceways, distribution racks, wholesale ladder racks

Click Here for Installation Instructions and detailed pictures of Ladder Rack

	ITEM NUMBER	DESCRIPTION
ICCMSLST10		Runway Section, 12-inches Wide x 10-foot Length
ICCMSLFT90		90? Turn Section, 12-inches Wide, flat turn.
ICCMSLIR90		Inside Radius Bend Section, 12-inches Wide
ICCMSLOR90		Outside Radius Bend Section, 12-inches Wide
ICCMSLAWSK		Kit, Wall Support, 12-inches Wide
ICCMSLTWSK		Kit, Wall Support, Triangle, 12-inches Wide
ICCMSLVWBK		Bracket, Vertical Wall Mount
ICCMSLCMRK		Kit, Ceiling Mount and Rod (2 Threaded rods included)
ICCMSLMFFK		Kit, Foot Floor Mount
ICCMSLRRBK		Bracket, Ladder to Relay Rack, 12-inches Wide
ICCMSLEBSK		Kit, End-to-end Butt Splice
ICCMSLTJSK		Kit, Runway Section, T-Junction Splice
ICCMSLCRPK		Kit, Cable Retaining Posts (includes 2 posts)
ICCMSLCRDK		Runway Center Radius Drop, 12-inches Wide

Miracel 19" Distribution Rack-Lab Rack NO 19

Miracel Network Racks
and Accessories (PDF, 1.0 MB)

■ with fixed 19" built-in unit on the front
■ for built-in units in accordance with IEC 297 3
■ flexible assembly of the built-in units using T slots

For the installation of
■ 19" components on the front
■ equipment with maximum width of 450 mm
■ installation accessories

Jumpering compartment
■ front 123 mm

Load rating
■ 5000 N static

Tests
■ earthing according to VDE 0100 part 540
■ vibration test according to MIL-STD 810 E

Material / Finish
■ basic rack, extruded aluminium, polished
■ corner piece die-cast aluminium
■ multifunctional frames and 19" angular extrusions sheet steel, zinc-plated

Supply schedule
1 basic unit
2 19" aluminium vertical extrusions with T slot and increment slide for spring nut M5
2 multifunctional frames for cable clamping and universal assembly options
4 levelling feet (0-25 mm)

How supplied
■ assembled

Please note
For the installation of chassis runners and 19" shelves, additional 19"- are required at the rear.
Rack Suites

To create a rack suite, per connection you require a set of suite connectors BN 1.130.935.7

Miracel NO19 (Width 600mm) with T-slot profile						Order Number
nominal depth	chassis depth	installation height	installation height	nominal height	weight
T [mm]	t [mm]	h [U]	h [mm]	H [mm]	[kg]
600	435	23	1052	1200	14	01.135.793.3
		37	1652	1800	16	01.135.795.3
		41	1852	2000	17	01.135.796.3
		46	2052	2200	18	01.135.797.3
700	435	23	1052	1200	15	01.135.799.3
		37	1652	1800	17	01.135.801.3
		41	1852	2000	18	01.135.802.3

800	635	23	1052	1200	16	01.135.817.3
		37	1652	1800	18	01.135.819.3
		41	1852	2000	19	01.135.820.3
		46	2052	2200	20	01.135.821.3
900	735	37	1652	1800	19	01.135.842.0
		41	1852	2000	20	01.135.843.0
		46	2052	2200	21	01.135.844.0

Miracel 19" Distribution Rack – Network Rack NS 26

Miracel Network Racks
and Accessories (PDF, 1.0 MB)

■ With fixed 19" installation on the front and rear for components in accordance with IEC 297-3
■ Installation of chassis runners and 19" shelves possible
■ Cable entry via bottom and top cover
■ Door opening angle, 180°

Variants
Type 1
■ single rack (with side panels)
Type 2
■ rack for rack suite (without side panels)

For the installation of
■ 19" components on the front and rear
■ equipment with maximum width of 450 mm
■ installation accessories

Jumpering compartment
■ front 123 mm

Load rating
■ 5000 N static

Degree of protection
IP 20 (upgradeble to IP 55)

Tests
■ Earthing in accordance with VDE 0100 T 540
■ IP Test in accordance with DIN 40 050 / IEC 529
■ Earthing in accordance with VDE 0100 T 540
■ IP Test in accordance with DIN 40 050 / IEC 529

Material / Finish
■ basis rack, extruded aluminium, polished
■ corner pieces, die-cast aluminium, polished
■ cover zinc-plated sheet steel, powder-coated textured
■ doors, sheet steel, ,powder-coated structure, glass infill front door, single security-glass panel, 4 mm
■ multifunctional members an 19"-extrusions sheet steel, zinc-plated

Colour
Final digit of order number .1:
■ Door trim RAL 9011 black
■ Visible surface of the cover RAL 7035 light grey
Final digit of order number .8:
■ Door trim RAL 9011 black
■ Visible surface of the cover RAL 7021 black grey

Supply schedule

Type 1
1 Basic rack 1 19" Vertical extrusions, sheet steel with mounting holes 2 Multifunctional struts for cable clamping and universal mounting options 2 Side panels with quick connectors 1 Cover with integrated cable entry 1 Front door, single, single safety glass panel, with handle and mounting for cylinder lock 1 Rear door, single, sheet steel, with handle and mounting for cylinder lock 1 Earth set, complete ( VDE 0100 ) 4 Levelling feet
Type 2
1 Basic rack 4 19" Vertical extrusions, sheet steel with mounting holes 2 Multifunctional struts for cable clamping and universal mounting options 1 Cover with integrated cable entry 1 Front door, single, single safety glass panel, with handle and mounting for cylinder lock 1 Rear door, single, sheet steel, with handle and mounting for cylinder lock 1 Earth set, complete ( VDE 0100 ) 4 Levelling feet
How supplied
■ assembled

Miracel NS26 (Width 800)								Order Number
type	width	height	depth	height	installation height	useable depth	weight
	[mm]	[mm]	[mm]	[U]	h [mm]	t [mm]	[kg]
with side panels	800	2000	600	41	1900	365	108	01.136.274.X
	8700	2000	800	41	1900	565	116	01.136.280.X
	800	2200	800	46	2100	565	126	01.136.281.X
	800	2000	900	41	1900	665	120	01.136.286.X
	800	2200	900	46	2100	665	130	01.136.287.X
without side panels	800	2000	600	41	1900	365	99	01.136.300.X
	800	2000	800	41	1900	565	105	01.136.306.X
	800	2000	900	41	1900	665	115	01.136.312.X

Replace X with the digit representing your colour choice

.1 = RAL 9011 / RAL 7035
■ Door trim RAL 9011 black
■ Visible surface of the cover RAL 7035 light grey

.8 = RAL 9011 / RAL 7021
■ Door trim RAL 9011 black
■ Visible surface of the cover RAL 7021 black grey

Miracel 19" Distribution Rack

Miracel 19" Distribution Rack NS 19.8, single winged

Miracel Network Racks
and Accessories (PDF, 1.0 MB

■ with fixed 19" built-in unit on the front
■ for built-in units in accordance with IEC 297 3
■ flexible assembly of the built-in units using T slots
■ cable entry via plinth and cover
■ heat loss discharge via ventilation dome
■ door opening angle 180°

Variants
Type 1
■ single rack (with side panels)
Type 2
■ rack for rack suite (without side panels)

For the installation of
■ 19" components on the front
■ equipment with maximum width of 450 mm
■ installation accessories

Jumpering compartment
■ front 123 mm

Load rating
■ 5000 N static

Degree of protection
Type 1
■ IP 40 (upgradeble to IP 55)

Tests
■ earthing according to VDE 0100 P 540
■ vibration test according to MIL-STD 810 E
■ IP test according to DIN 40 050 / IEC 529

Material / Finish
■ Basic rack, aluminium extrusion, polished
■ Corner piece, die-cast aluminium, polished
■ Covers, sheet steel, zinc passivated, powder-caoted, textured
■ Doors, sheet steel, powder-coated, textured, glass infill, front door, single safety glass panel, 4 mm
■ Multifunctional struts and 19" extrusions, sheet steel, zinc passivated

Colour
■ Door trim RAL 9011 black
■ Visible surface of the cover RAL 7035 light grey

Supply schedule
Type 1
1 Basic unit
2 19" aluminium vertical extrusion with T slot and increment slide for spring nut M5
2 Multifunctional frame for cable clamping and universal assembly options
1 Cover with ventilation dome and integrated cable entry
1 Front door, single-winged, single security glass panel, with handle and fixing for locking cylinders
1 Rear door, single-winged, sheet steel, with handle and fixing for locking cylinders
2 Side panels with quick locking
1 Plinth for cable entry on the side and rear with levelling feet (0-25 mm)
2 lateral plinth trim, closed
2 Plinth trim for front and rear, with airing vents and fixing for filter mat
1 Complete earthing test (VDE 0100)
Type 2
1 Basic unit
2 19" aluminium vertical extrusion with T slot and increment slide for spring nut M5
2 Multifunctional frame for cable clamping and universal assembly options
1 Cover with ventilation dome and integrated cable entry
1 Front door, single-winged, single security glass panel, with handle and fixing for locking cylinders
1 Rear door, single-winged, sheet steel, with handle and fixing for locking cylinders
1 Plinth for cable entry on the side and rear with levelling feet (0-25 mm)
2 Plinth trim for front and rear, with airing vents and fixing for filter mat
1 Complete earthing test (VDE 0100)

How supplied
■ assembled

Please note
For the installation of chassis runners and 19" shelves, additional 19"- are required at the rear. (in the Miracel 19" distribution rack NS 25 as standard).
Rack Suites

To create a rack series with the rack number, you require:
(n-1) racks without side panels
1 rack with side panels
In a rack suite, per connection you require a set of suite connectors BN 1.130.935.7

Miracel NS19.8 (Width 800mm) with a single-winged glass door							Order Number
type	nominal depth	chassis depth	installation height		nominal height	weight
	T [mm]	t [mm]	h [U]	h [mm]	H [mm]	[kg]
with side panels	600	435	23	1052	1320	78	01.135.001.1
			37	1652	1920	103	01.135.003.1
			41	1852	2120	112	01.135.004.1
			46	2052	2320	121	01.135.005.1
	800	635	23	1052	1320	80	01.135.019.1
			37	1652	1920	111	01.135.021.1
			41	1852	2120	120	01.135.022.1
			46	2052	2320	129	01.135.023.1
without side panels	600	435	23	1052	1320	70	01.135.007.1
			37	1652	1920	95	01.135.009.1
			41	1852	2120	103	01.135.010.1
			46	2052	2320	112	01.135.011.1
	800	635	23	1052	1320	73	01.135.025.1
			37	1652	1920	101	01.135.027.1
			41	1852	2120	109	01.135.028.1
			46	2052	2320	118	01.135.029.1

Miracel 19" Distribution Rack – Network Rack NS 25

Miracel Network Racks
and Accessories (PDF, 1.0 MB)

■ installation of chassis runners and 19" shelves possible
■ with fixed 19" built-in unit on the front and rear
■ for built-in units in accordance with IEC 297 3
■ flexible assembly of the built-in units using T slots
■ cable entry via plinth and cover
■ heat loss discharge via ventilation dome
■ door opening angle 180°

Variants
Type 1
■ single rack (with side panels)
Type 2
■ rack for rack suite (without side panels)

For the installation of
■ 19" components on the front and rear
■ equipment with maximum width of 450 mm
■ installation accessories

Jumpering compartment
■ front 123 mm

Load rating
■ 5000 N static

Degree of protection
IP 40 (upgradeble to IP 55)

Tests
■ earthing according to VDE 0100 P 540
■ vibration test according to MIL-STD 810 E
■ IP test according to DIN 40 050 / IEC 529

Supply schedule
type 1
1 basic unit
4 19" aluminium vertical extrusions with T slot and increment slide for spring nut M5
2 multifunctional frame for cable clamping and universal assembly options
1 cover with ventilation dome and integrated cable entry
1 front door, single-winged, single security glass panel, with handle and fixing for locking cylinders
1 rear doors, sheet steel, with handle and fixing for locking cylinders
2 side panels with quick locking
1 plinth for cable entry on the side and rear with levelling feet (0-25 mm)
2 lateral plinth trim, closed
2 plinth trims for front and rear, with airing vents and fixing for filter mat
1 complete earthing test (VDE 0100)
type 2
1 basic unit
4 19" aluminium vertical extrusions with T slot and increment slide for spring nut M5
2 multifunctional frame for cable clamping and universal assembly options
1 cover with ventilation dome and integrated cable entry
1 front door, single-winged, single security glass panel, with handle and fixing for locking cylinders
1 rear doors, sheet steel, with handle and fixing for locking cylinders
1 plinth for cable entry on the side and rear with levelling feet (0-25 mm)
2 plinth trims for front and rear, with airing vents and fixing for filter mat
1 complete earthing test (VDE 0100)

How supplied
■ assembled

Please note
Rack suites
To create a rack series with the rack number n, you require:
(n-1) racks without side panels
1 rack with side panels
In a rack suite, per connection you require a set of suite connectors BN 01.130.935.7

Miracel NS25 (Width 800mm)							Order Number
type	nominal depth	chassis depth	installation height		nominal height	weight
	T [mm]	t [mm]	h [U]	h [mm]	H [mm]	[kg]
with side panels	600	365	41	1852	2120	112	01.136.044.1
	600	365	41	1852	2120	112	01.136.044.8
	800	565	41	1852	2120	120	01.136.050.1
			41	1852	2120	120	01.136.050.8
			46	2052	2320	130	01.136.051.1
			46	2052	2320	130	01.136.051.8
	900	665	41	1852	2120	124	01.136.056.1
			41	1852	2120	124	01.136.056.8
			46	2052	2320	134	01.136.057.1
			46	2052	2320	134	01.136.057.8
	1000	740	41	1852	2120	140	01.127.970.1
	1000	740	41	1852	2120	140	01.127.970.8
without side panels	600	365	41	1852	2120	103	01.136.244.1
	600	365
	800	565	41	1852	2120	109	01.136.250.1
	800	565	41	1852	2120	109	01.136.250.8
	900	665	41	1852	2120	118	01.136.256.1
	900	665	41	1852	2120	118	01.136.256.8
	1000	740	41	1852	2120	128	01.127.975.1
	1000	740	41	1852	2120	128	01.127.975.8

Miracel 19" Network Equipment Rack NG 800

Miracel Network Racks
and Accessories (PDF, 1.0 MB)

■ cable entry via plinth and cover
■ heat loss discharge via ventilation dome
■ door opening angle 180°

Variants
Type 1
■ single rack (with side panels)
Type 2
■ rack for rack suite (without side panels)

For the installation of
■ equipment with maximum width of 735 mm
■ shelves
■ installation accessories

Load rating
■ 5000 N static

Degree of protection
Type 1
■ IP 40 (upgradeble to IP 55)

Tests
■ earthing according to VDE 0100 P 540
■ vibration test according to MIL-STD 810 E
■ IP test according to DIN 40 050 / IEC 529

Material / Finish
■ basic rack, extruded aluminium, polished
■ corner pieces, die-cast aluminium, polished
■ covers zinc-plated sheet steel, powder-coated textured
■ doors, sheet steel, powder-coated structure, glass infill front door, single security-glass panel, 4 mm
■ multifunctional members and 19"-extrusions sheet steel, zinc-plated

Colour
■ Door trim RAL 9011 black
■ Visible surface of the cover RAL 7035 light grey

Supply schedule
Type 1
1 basic unit
2 multifunctional frame for cable clamping and universal assembly options
1 cover with ventilation dome and integrated cable entry
1 front door, single-winged, single security glass panel, with handle and fixing for locking cylinders
1 rear door, single-winged, sheet steel, with handle and fixing for locking cylinders
2 side panels with quick locking
1 plinth for cable entry on the side and rear with levelling feet (0-25 mm)
2 lateral plinth trim, closed
2 plinth trims for front and rear, with airing vents and fixing for filter mat
1 complete earthing test (VDE 0100)
Type 2
1 basic unit
2 multifunctional frame for cable clamping and universal assembly options
1 cover with ventilation dome and integrated cable entry
1 front door, single-winged, single security glass panel, with handle and fixing for locking cylinders
1 rear door, single-winged, sheet steel, with handle and fixing for locking cylinders
1 plinth for cable entry on the side and rear with levelling feet (0-25 mm)
2 plinth trims for front and rear, with airing vents and fixing for filter mat
1 complete earthing test (VDE 0100)

How supplied
■ assembled

Rack Suites
To create a rack series with the rack number n, you require:
(n-1) racks without side panels
1 rack with side panels
In a rack suite, per connection you require a set of suite connectors BN 01.130.935.

Miracel NG800 (Width 800mm) with glass door, single-winged							Order Number
type	nominal depth		height			weight
	T [mm]	t1 [mm]	H [U]	H [mm]	h [mm]	[kg]
with side panels	800	730	23	1320	1052	77	01.135.649.1
			37	1920	1652	107	01.135.651.1
			41	2120	1852	115	01.135.652.1
			46	2320	2052	124	01.135.653.1
without side panels	800	730	23	1320	1052	70	01.135.655.1
			37	1920	1652	97	01.135.657.1
			41	2120	1852	104	01.135.658.1
			46	2320	2052	113	01.135.659.1

. standard depths of 3, 4, 5, and 6 inches
5. standard lengths of 10, 12, 20 and 24 feet
Solid Bottom cable tray is generally used for minimal heat generating electrical or telecommunication applications with short to intermediate support spans of 5 feet to 12 feet.

3. Trough Cable Tray provides:
1. Moderate ventilation with added cable support frequency and with the bottom configuration providing cable support every 4 inches. Available in metal and nonmetallic materials.
2. standard widths of 6, 12, 18, 24, 30, 36 inches
3. standard depths of 3, 4, 5, and 6 inches
4. standard lengths of 10, 12, 20 and 24 feet
5. fixed rung spacing of 4 inch on center
Trough cable tray is generally used for moderate heat generating applications with short to intermediate support spans of 5 feet to 12 feet.

4. Channel Cable Tray provides:
1. an economical support for cable drops and branch cable runs from the backbone cable tray system.
2. standard widths of 3, 4, and 6 inches in metal systems and up to 8 inches in nonmetallic systems.
3. standard depths of 1¼-1¾ inches in metal systems and 1, 1 1/8, 1 5/" and 2 3/16 inches in nonmetallic systems
4. standard length of 10, 12, 20 and 24 feet
Channel cable tray is used for installations with limited numbers of tray cable when conduit is undesirable. Support frequency with short to medium support spans of 5 to 10 feet.

5. Wire Mesh Cable Tray provides:
1. A job site, field adaptable support system primarily for low voltage, telecommunication and fiber optic cables. These systems are typically steel wire mesh, zinc plated.
2. standard widths of 2, 4, 6, 8, 12, 16, 18, 20, and 24 inches
3. standard depths of 1, 2, and 4 inches
4. standard length of about 10 feet (118")
Wire Mesh tray is generally used for telecommunication and fiber optic applications and are installed on short support spans, 4 to 8 feet.

6. Single Rail Cable Tray provides:
1. These aluminum systems are the fastest systems to install and provide the maximum freedom fort cable to enter and exit the system.
2. Single hung or wall mounted systems in single or multiple tiers.
3. Standard widths are 6, 9, 12, 18, and 24 inches.
4. Standard depths are 3, 4, and 6 inches.
5. Standard lengths are 10 and 12 feet.
Single Rail Cable Tray is generally used for low voltage and power cables installations where maximum cable freedom, side fill, and speed to install are factors.

What materials / finishes are available for the various cable tray systems?

1. Steel (Min. Yield = 33KSI) (35 KSI for Stainless)
1. Plain: hot rolled pickled and oiled steel per ASTM A569 (Commercial Quality) or A570 (Structural Quality)
2. Pre-Galvanized: mill galvanized steel per ASTM A653 CS (Commercial) or SS (Structural) G90
3. Hot Dip Galvanized After Fabrication: plain steel which is hot dipped after fabrication per ASTM A123.
4. Stainless Steel: type 304 or 316L fully annealed stainless steel

2. Aluminum (Min.Yield = 23 KSI)
1. 6063-T6 or 5052-H32 alloy per ASTM B209

3. Fiber Reinforced Plastic (FRP)
1. Polyester and Vinyl Ester resin systems available
2. meet ASTM E-84 smoke density rating; Polyester 680, Vinyl Ester 1025
3. Class 1 Flame Rating and self-extinguishing requirements of ASTM D-635.

Now that I know what types of cable trays are available, what configurations are available?

1. Straight sections are available to route cables in a horizontal or vertical plane.
2. Fittings are available to route cables in various directions in either the horizontal or vertical planes. Typical examples of fittings include elbows, tees, crosses, and risers. Each of these fittings are available in various radii and bend angles.
3. Covers are accessories and shouldn't be in here unless splices etc. are included.

After selecting the type of cable tray and configuration required, what support methods are available?

1. Trapeze Support (Single or Multi-tier)
2. Hanger rod clamps, "J" hangers
3. Center Hung Support
4. Wall Support
5. Underfloor Support
6. Pipe stanchions or other structures

Each of these support methods are preferable in different applications. For instance, trapeze supports may be desired in an application where cables will be pulled through the cable tray. Center hung supports, on the other hand, are generally used when cables will be installed from the side of the cable tray. Center hung supports are especially useful when future cable additions are desired. Wall supports and underfloor supports are useful when ceiling structure is not available or undesired. Outdoor installations are controlled by the structures available to support the cable tray.
Before selecting the type of cable tray, cable tray configuration(s), and support method desired, what additional information do I need to supply to the cable tray manufacturer for them to best understand and satisfy my needs?

1. Where? Job site and installation considerations
1. Outdoor
1. supports available affect the length and strength requirements
2. environmental loads, ice, wind, snow, and possibly seismic
3. corrosion requirements affect the materials and finishes
4. classified hazardous locations affect the cable types acceptable
2. Indoor
1. support locations available affect the length and strength of the system
2. industrial installation may require a 200 lb. Concentrated Load
3. commercial or institutional installation may make system appearance, system weight, and space available important factors
4. environmental air handling area may affect cable types, cable tray material, or cable tray type and need for covers
5. classified hazardous locations affect the cable types acceptable

2. What?
1. Type and number of cables to support
1. NEC cable fill requirements dictate size, width and depth, of system
2. cable support requirement may control bottom type
3. largest bending radius of cable controls fitting radius
4. total of cable weight determines load to support
2. Future requirements
1. cable entry / exit freedom
2. design partially full or an expandable system
3. support type to allow for needs

Call (866) 342-3721 Or Click On The Chat Button At The Top Of The Page To Talk To One Of Our Representatives

Raceway Systems-Cable Management Solutions- Ladder Racks- Wholesale ladder Racks-Cable Management Solutions- WireTrays - Distribution Racks- Raceway- Relay Racks- CableTies-Cable Management- Cable Wraps-Finger Duct Panels
