PE 89-Copper Telecom Cables- Seal Pic FSF PE 89- Seal Pic FSF PE 39- Black Jacket-Direct Bury Copper Telephone Cables- 25 Pair PE 89

American Tele Data Carries a complete line of PE 89 direct bury copper telephone cables including the Seal Pic FSF PE 89 and Seal Pic FSF PE 39 cables which come in 25 pair to 200 pair PE 89 configurations. The PE 89 or Seal Pic FSF PE 89 and Seal Pic FSF PE 39 cables are used for distribution and long distance networks. The Seal Pic FSF 89 comes in 22 gauge and 24 gauge copper cable. The Seal Pic FSF 39 cables come in 19 gauge and 22 gauge coper. These cables are installed into ducts. The manufacturer Hesfibel provided the majority of the recent Times Warner build out and operates on the principle of minimum error and the provision of high quality products and total customer satisfaction. Hesfibel has been awarded the TSE-ISO 9002 quality certification since 1993.

Call for pricing, minimum order $500.00- please


West Coast (866) 342-3721
New Southern CA Office ( 760) 471-8200
East Coast (866) 650-3282

Stub Cable- Transition Cable-PE 89, 25 Pair PE 89, Copper Telecom Cables,Seal Pic FSF PE 89- Transition Cables- Seal Pic FSF PE 39- Stub Cables- Direct Bury Copper Telecom Cables-Icky Pick

West Coast Sales (866) 342-3721 East Coast Sales (866) 650-DATA

American Tele Data carries a complete line of stub cable, transition cable, andPE 89 direct bury copper telephone cables including the Seal Pic FSF PE 89 and Seal Pic FSF PE 39 cables which come in 25 pair to 200 pair PE 89 configurations. The PE 89 or Seal Pic FSF PE 89 and Seal Pic FSF PE 39 cables are used for distribution and long distance networks. The Seal Pic FSF 89 comes in 22 gauge and 24 gauge copper cable. The Seal Pic FSF 39 cables come in 19 gauge and 22 gauge coper. These cables are installed into ducts. The manufacturer Hesfibel provided the majority of the recent Times Warner build out and operates on the principle of minimum error and the provision of high quality products and total customer satisfaction. Hesfibel has been awarded the TSE-ISO 9002 quality certification since 1993.

Stub Cable

Stub Cable- Stub Cable is factory process filled cable that is cut to customer specified lengths eliminating time-consuming cable preparation at the customer job site. The Stub Cable features a factory installed pneumatic cable "block" on one end of the cable (a variety of cable types are available; 22, 24, 26 gauge cable with pair counts from 50 to 1800 pair sizes). The cable block prevents air and/or filling compound leakage from pressurized cable plant to non-pressurized cable plant. The cable block is typically located 120 inches from one end of the cable and is sealed using state of the art blocking compounds. The cable block is small in diameter relative to the cable diameter to minimize obstructions and clearances from adjacent cable plant.

Copper Interconnect Enclosures

Transition cable- Transition Cable is a factory processed filled cable that is pre-cut to custom lengths. This eliminates time-consuming on-site preparation and the use of hazardous cleaning chemicals in the field. Additionally, cables can be provided with optional factory-installed connector modules and pulling eyes.

American Tele Data CARRIES PE – 89 Communication Cable which comes in a six (6) pair cable configurations up to 2400 pairs manufactured for the purpose of direct burial systems communication applications in accordance with the National Electric Code.Conductor construction is soft drawn bare copper meeting the requirements of ASTM Specification B-3. The conductors are 22 awg solid copper.The conductors are insulated with polyethylene (PE) in distinctive colors to facilitate pair identification and are twisted into pairs with varying lays to minimize crosstalk.The interstices between the pairs are filled with an 80 C filling compound and covered with a low density, high molecular weight black polyethylene (PE).

The assembly is then wrapped with two metal shield tapes:

- A corrugated .008" thick polymer coated aluminum tape and a corrugated .006" polymer coated steel tape.

Application:

Suitable for use as direct burial communication applications where protection against water and moisture entry is a critical requirement. PE – 89 is recommended where rodent attack is possible.


Construction:

Conductor: Soft drawn bare copper (ASTM Spec. B-3). Solid (22 awg)

Inner Jacket: Polyethylene (PE)

Outer Jacket: Polyethylene (PE)

Temperature: 60 C

Resistance: 17.235 OHMS PER M FEET at 68 DEG. F


Call for pricing, minimum order $500.00- Please- American Tele Dataoffers cutting of cable-For custom cable lengths at an additional cost-

West Coast (866) 342-3721
New Southern CA Office ( 760) 471-8200
East Coast (866) 650-3282

For More Information On Any of the Products Below- Just click on the Pictures -More Information and Specifications For PE 39 and PE 89 Below

PE 89 Application:
For use in wet environments where protection from moisture is required. Approved for direct burial, duct or aerial installations when supported by a messenger.

PE 89 Conductors:
Solid soft bare annealed copper. Individual conductors are twisted into pairs with varying lay lengths to minimize crosstalk.

PE 89 Insulation:
Dual layer of foamed polyolefin and solid polyolefin.

PE 89 Filling Compound:
Cable core is filled with an extended thermoplastic rubber (ETPR) filling the interstices between the pairs and under the core tape.

PE 89 Core Wrap:
Non-hygroscopic, dielectric tape with overlap.

PE89 Shield:
Corrugated, copolymer coated, 8-mil aluminum tape longitudinally applied with overlap. The shield interfaces are flooded with an adhesive compound to provide a moisture barrier and inhibit corrosion.

PE 89 Jacket:
Black, sunlight-resistant, linear low-density polyethylene.

Additional Standards:
• ANSI/ICEA S-84-608-1994 • RUS 7 CFR 1755.890 (formerly REA PE-8





Call for pricing, min order $500.00 please


American Tele Data carries a complete line of PE 89 direct bury copper telephone cables including the Seal Pic FSF PE 89 and Seal Pic FSF PE 39 cables which come in 25 pair to 200 pair PE 89 configurations. The PE 89 or Seal Pic FSF PE 89 and Seal Pic FSF PE 39 cables are used for distribution and long distance networks. The Seal Pic FSF 89 comes in 22 gauge and 24 gauge copper cable. The Seal Pic FSF 39 cables come in 19 gauge and 22 gauge coper. These cables are installed into ducts. The manufacturer Hesfibel provided the majority of the recent Times Warner build out and operates on the principle of minimum error and the provision of high quality products and total customer satisfaction. Hesfibel has been awarded the TSE-ISO 9002 quality certification since 1993.

Description:

American Tele Data CARRIES PE – 89 Communication Cable which comes in a six (6) pair cable confifuration up to 2400 pairs manufactured for the purpose of direct burial systems communication applications in accordance with the National Electric Code.Conductor construction is soft drawn bare copper meeting the requirements of ASTM Specification B-3. The conductors are 22 awg solid copper.The conductors are insulated with polyethylene (PE) in distinctive colors to facilitate pair identification and are twisted into pairs with varying lays to minimize crosstalk.The interstices between the pairs are filled with an 80 C filling compound and covered with a low density, high molecular weight black polyethylene (PE).

The assembly is then wrapped with two metal shield tapes:

- A corrugated .008" thick polymer coated aluminum tape and a corrugated .006" polymer coated steel tape.

Application:

Suitable for use as direct burial communication applications where protection against water and moisture entry is a critical requirement. PE – 89 is recommended where rodent attack is possible.


Construction:

Conductor: Soft drawn bare copper (ASTM Spec. B-3). Solid (22 awg)

Inner Jacket: Polyethylene (PE)

Outer Jacket: Polyethylene (PE)

Temperature: 60 C

Resistance: 17.235 OHMS PER M FEET at 68 DEG. F



Call for pricing, minimum order $500.00- Please- American Tele Dataoffers cutting of cable-For custom cable lengths at an additional cost-


West Coast (866) 342-3721
New Southern CA Office ( 760) 471-8200
East Coast (866) 650-3282

For More Information On Any of the Products Below- Just click on the Pictures -More Information and Specifications For PE 39 and PE 89 Below

PE 89 Application:
For use in wet environments where protection from moisture is required. Approved for direct burial, duct or aerial installations when supported by a messenger.

PE 89 Conductors:
Solid soft bare annealed copper. Individual conductors are twisted into pairs with varying lay lengths to minimize crosstalk.

PE 89 Insulation:
Dual layer of foamed polyolefin and solid polyolefin.

PE 89 Filling Compound:
Cable core is filled with an extended thermoplastic rubber (ETPR) filling the interstices between the pairs and under the core tape.

PE 89 Core Wrap:
Non-hygroscopic, dielectric tape with overlap.

PE89 Shield:
Corrugated, copolymer coated, 8-mil aluminum tape longitudinally applied with overlap. The shield interfaces are flooded with an adhesive compound to provide a moisture barrier and inhibit corrosion.

PE 89 Jacket:
Black, sunlight-resistant, linear low-density polyethylene.

Additional Standards:
• ANSI/ICEA S-84-608-1994 • RUS 7 CFR 1755.890 (formerly REA PE-8
