Patch Panels- 24 Port Telco Patch Panels- 48 Port Telco Patch Panels- 72 Port Patch Panels- 96 Port Patch Panels-110 Telco Patch Panels- Relay Racks- Data Cabinets-ICC Telco Patch Panels

American Tele Data Tele Data carries a complete line of patch panels including 12 Port Patch Panels, 24 port patch panels, 48 port patch panels, 72 Port Patch Panels, 96 Port Patch Panels and 110 telco patch panels for computer rooms, data, telco, 110 and USOC applications. Our patch panels offer quality and affordable cross-connect solutions (CXS) to meet every requirement - from a consolidation point-to a complete telecommunications room. We also have a complete array of relay racks and data cablinets. Our relay racks start at $ 99.00 per rack for 7 foot brushed Aluminum in quantities of 5 or more.

Southern CA (619) 573-4164 ------ (866) 650-3282------EAST (866) 650-3282

Keystone Patch Panel Pricing -Part Numbers- ICC- Signamax-Ortronics-AMP- Superior-Panduit-Leviton-& More Available
Patch Panel Description Pricing Is For 0ne- Please Ask For Additional Quantity Discounts Pricing* Minimum Orders May Be Required
ICMPP12V5E CAT 5e 12-Port Vertical Patch Panel -More Info

ICMPP12V5E 12-Port-CAT 5e Vertical Patch Panel comes Pre-configured for T-568B wiring and includes an easy to insert label for T-568A wiring. Designed for easy mounting during installation, the panel is CAT 5e compliant, and provides a reliable and consistent termination.

Price: $52.00

Price: $52.00 each

Click here for more info on Signamax 12 Port Vertical Patch Panels

PT# 12458M-C5E-12-Port Category 5e+ Mini Panel w/89D Bracket, T568A/B Wiring

PT#12458MH-C5E-12-Port Category 5e+ Mini Hinged Panel, T568A/B Wiring

Our Signamax vertical CAT 5e mini Patch Panels are available in 12-port size and are ideal for installations where space is at a premium and open bay racks cannot be used. Panels are designed to exceed TIA/EIA-568-B.2 component level specifications and include port numbering, write-on labeling areas and are compatible with both T568A and T568B wiring configurations. Panels are provided mounted to either an 89D bracket or in a hinged version, both of which allow for easy access to the back of the panel for termination to 110 connectors.

PT# 12458M-C5E $ 54.00

PT#12458MH-C5E $84.00

Keystone Vertical 12 Port Patch Panel -PT# ATDBL102201-C5e-More Info

BEST PRICED PATCH PANELS IN THE USA-EIA-TIA -UL LISTED!

Vertical CAT 5e mini Patch Panels are available in 12-port size and are ideal for installations where space is at a premium and open bay racks cannot be used. Exceeds TIA/EIA CAT 5e standards. Includes mounting screws.

ATDBL102201-C5e

$28.88 each

Leviton 12 Port Gigabit Vertical Patch Panel-More Info PT#-LE-5G596-U12 Leviton GigaMax 5e Universal Patch Panel - 12 Port Patch Panel- Leviton GigaMax™ 5e Patch Panels and patch blocks are one of the most popular patch panel systems for providing outstanding Category 5e performance with user friendly features. It is an easy-to-install panel for any modular cross connect system with 110 punch downs in the rear of the panel with six port RJ-45 modules on the front. Available in 12, 24, 48, and 96 port configurations, and 12-port patch block. These patch panels are UL certified, and meet or exceed all TIA/EIA-568-B for Category 5e requirements and meets FCC Part 68.

PT#-LE-5G596-U12

$ 86.88 each

Panduit 12 Port vertical Patch Panel -PT# DP125E88TGY Category 5e Punchdown Style Patch Panels feature:
• Exceeds all Category 5e requirements including POWERSUM ACR, ELFEXT and Return Loss
• Protective circuit board cover
• Removable 6-port circuit board design
• Punchdown style termination on back of patch panel
• Wiring scheme clearly identified on universal label
• Terminates 4-pair 24 and 22 AWG 100 ohm unshielded twisted pair cable
•Integral cable tie mounts
• Accepts icons for part indentification

PT# DP125E88TGY-

$68.88 each

Hubbell 16 Port Patch Panel Model # P5E24UE

Hubbell offers a complete range of easy-to-use front access cross connect solutions. The 12- and 24-port front access panels offer a unique design that allows access to both modular jacks and IDC connectors from the front. Front access panels are typically used in small-scale applications where space is limited and front access is necessary. These panels are an ideal consolidation point and MUTOA solution.

  • Universal wiring: panels can be terminated using either T568B or T568A wiring schemes
  • Patented panel ID label holders accept Hubbell laser printable label sheets and industry recognized .5" hand held printer tape
  • Rolled edge construction provides rugged strength to eliminate flex during termination
  • Extra wide IDC spacing provides increased space for lacing, terminating, and routing cable
  • Optional cable management/strain relief bar (PCBLMGT) clips to the rear of panel without additional hardware
  • Utilizes 110 inline paired punch-down

Model # P5E12BF

Price $ 89.88 Each

AMP CAT 6 12 Port Patch Panel 1479153-1 AMP SL Series Patch Panel, Category 5E, Unshielded, 12-Port, Straight, 10.00 in x 2.3 in

PT # 1479153-1

Price $ 98.88 ea

Leviton 12 Port Gigabit Vertical Patch Panel-More Info Leviton 12 Port CAT 6 Patch Panels PT # 69586-U12 Leviton CAT 6 12 Port Patch Panels set the bar higher for mechanical and electrical excellence with Leviton’s top-of-the-line, error-free Category 6 performance. Optimized for maximum throughput and a zero bit error rate, eXtreme 6+ System components meet or exceed the requirements for channel/component-level performance per TIA/EIA Category 6.



PT # 69586-U12

Price $148.88 each

8 Port Vertical Blank Panel PT# IC107PP8VB Black:Price:$11.72

ICC Vertical Blank Patch Panel - 8 Ports

PT# IC107PP8VB

Price:$11.72

ICC 12 Port Blank Patch Panel-IC107PP012-Black Price: $ 15.11

ICC 12 Port Patch Panel



PT# IC107PP012

$ 15.11 each

ICC 24 Port CAT 5e Patch Panel

ICMPP24F5E 24-Port, 1 RMS-This panel is designed to allow for front access patching and termination, while wall or rack mounted. The panel provides both the 110 IDC termination and the Category 5e jack ports on the same side. Ideal for applications with limitations in space. Includes #12 rack screws.

ICMPP24F5E

Price Price: $110.00

ICC 24 Port Hinged Patch Panel PT # ICMPP24H5E ICC 24 Port Hinged PATCH PANEL, HINGED, 24-PORT, 2 RMS24-port hinged patch panel is designed to allow for front cable access and 110 punch down, while rack mounted. The panel comes equipped with a cable management interbay panel that allows the panel to fold down for punch down and then folds back into place. Includes mounting screws.

PT #ICMPP24H5E

$ 132.30 ea

Telco Patch Panel PT # ICMPP024T2 24-Port Telco Patch Panel, 6P2C-Integrated with 1 male telco connector. Includes mounting screws.PATCH PANEL, TELCO, 6P2C, 24-PORT, 1 RMS

PT # ICMPP024T2

$ 55.63 ea

ICC Elite IC108PP024 -- black - 24 Port Front Loading Patch Panel ICC Front Loading Blank Patch PanelPATCH PANEL, BLANK ELITE 24-BEZEL, 4 RMS Reinforced steel panels, pre-numbered and designed to accept twenty-four front loading Elite bezel modules for true multimedia.

PT # IC108PP024

Call For Pricing

IC107BP241 -- black-ICC 24 Port High Density Blank Patch Panel -1 RMS 24-Port High Density Blank Patch PanelPATCH PANEL, BLANK, HD, 24-PORT FLUSH, 1 RMS 24-port high density version provides room for 24 ports in one rack mount space (1 RMS).

IC107BP241

$22.31 ea

IC107PPS16 -- Black- ICC 16 Port Sctp Panel 16-Port Blank ScTP Panel-Accommodates ScTP connectors providing protection from EMI and other external interference.PATCH PANEL, BLANK, SCTP, 16-PORT, 1 RMS

Part # IC107PPS16

Price $ 39.94 ea

IC107PPS32 -black- ICC 32 Port Blank SCTP Panel 32-Port Blank ScTP Panel-Accommodates ScTP connectors providing protection from EMI and other external interference.PATCH PANEL, BLANK, SCTP, 32-PORT, 2 RMS - 32-Port Blank ScTP Panel

PT # IC107PPS32



Price $34.62ea

IC107PPS48 -black- ICC 48 Port Blank SCTP Panel 48-Port Blank ScTP Panel-PATCH PANEL, BLANK, SCTP, 48-PORT, 3 RMSAccommodates ScTP connectors providing protection from EMI and other external interference.

PT # IC107PPS48

Price $43.85 ea

IC107PPS64 - black- ICC 64 Port Blank Patch Panel 64-Port Blank ScTP Panel-PATCH PANEL, BLANK, SCTP, 64-PORT, 4 RMS - Accommodates ScTP connectors providing protection from EMI and other external interference.

PT# IC107PPS64

Price $53.08

ICMPP0485E -- black- ICC 48 Port CAT 5e Patch Panel PATCH PANEL, CAT 5E, 48-PORT- 2 RMS 48-Port CAT 5e Patch PanelExceeds TIA/EIA CAT 5e standards. Includes mounting screws.

Part Number ICMPP0485E

Price $149.29ea

Signamax Click Here for more about 24 Port Vertical Patch Panels

Category 5e+ Patch Panel

Part Number

Description

12458MD-C5E

12-Port Category 5e+ Patch Panel, T568A/B Wiring

24458MD-C5E

24-Port Category 5e+ Patch Panel, T568A/B Wiring

48458MD-C5E

48-Port Category 5e+ Patch Panel, T568A/B Wiring

96458MD-C5E

96-Port Category 5e+ Patch Panel, T568A/B Wiring

SMB-350

Panel Mount Cable Management Bar, 3.5” Deep

Panels include an integrated cable management feature for cable routing and strain relief requirements. An optional cable management bar, which easily mounts to the back of the panel, is available for improved routing and strain relief functions.

Category 5e+ patch panels are designed to exceed TIA/EIA-568-B.2 component, permanent link and channel level performance specifications providing usable bandwidth beyond 155 MHz. These high-density panels are available in 12 through 96 port versions and feature enhanced front and rear labeling features for easy circuit identification. Category 5e+ panels support both T568A and T568B wiring configurations using an easy to read color-coded wiring label.

Panels are constructed for maximum strength and durability and feature a fully enclosed, 6-port modular design, which provides flexibility and protection of printed circuitry during termination. Rear termination is made quick and easy using a 4-pair inline 110 type connector compatible with standard multi-pair impact tool to reduce installation time or single position 110 or Krone termination tool.



24458MD-C5E

Click Here For Pricing



PT # 5G596-U24-GigaMax 5e Universal 24-port Patch Panel, CAT 5e, 1.75"H x19"W, black-Leviton 12 Port Gigabit Vertical Patch Panel-More Info Leviton 12 Port CAT 6 Patch Panels PT # 69586-U12

  • Universal printed circuit-board modules with 110-style IDC punchdowns can be used for T568A and T568B wiring configurations.
  • UL Listed; meet National Electrical Code requirements and specifications for UL 1863; and fully comply with the latest published TIA guidelines
  • Connector spring wire contacts are constructed with highest quality phosphor bronze, plated with 50 microinches of gold over 100 microinches of nickel.
  • Patch Panels feature color-coded front labeling for easy port identification.

PT # 5G596-U24

$ 114.88 each

PT# DP245E88TGY- Panduit 24 Port Patch Panel
  • Terminates 4 pair, 22 - 24 AWG, 100 ohm, solid or stranded twisted pair cable
  • Mount to standard EIA 19" rack or 23" racks with optional extender bracket
    - All materials are UL94V0 Compliant
  • Write-on areas for port and panel identification available
  • Can be clearly identified with labels and icons
    - Dymo Rhino Pro Label maker has pre-programmed patch panel settings for easy label printing.
    - All patch panels come with four (4) 12-24 x ½” round head screws for fastening to racks
  • Also available in angled versions which allow for higher density installations by easily routing the patch cords to each side of the panel eliminating the need for horizontal cable management
  • Cat 5e panels exceed TIA/EIA-568-B.2 Category 5e and ISO11801 Class D standards
  • Cat 6 panels exceed TIA/EIA-568-B.2-1 Category 6 and ISO11801 Class D standards
  • Each port is 100% tested to ensure NEXT and return loss performance and is individually serialized to support traceability
  • Utilizes 110 termination on back panel
  • Each port contains a universal label that is color coded for T568A and T568B wiring schemes

PT# DP245E88TGY

$ 192.88 each

OR-PSD5E6U24HM- Ortronics 24 Port CAT 5e Patch Panel Clarity5E 24-port standard density patch panel with hinged cable management panel is component compliant to TIA/EIA Category 5e performance requirements. It occupies 4 rack units and measures 19" x 7.0". Jacks are grouped in six-port modules. It is part of the Clarity5E link and channel solution that provides significant installed performance headroom.

OR-PSD5E6U24HM

Call For Pricing

PT # DCC2488/25V01-Superior 24 Port Patch Panels- Superior 24 Port Cat 5e Patch Panels • Black exterior • High density profile write-on port labels and 110 style connecting blocks for rear termination • Patented technology. • Comfortably exceeds all EIA/TIA 568-A, Cat 5 & 5e Superior: Cat 5e Patch Panels • Black exterior • High density profile write-on port labels and 110 style connecting blocks for rear termination • Patented technology. • Comfortably exceeds all EIA/TIA 568-A, Cat 5 & 5e specifications Compliant with ISO/IEC11801 and ANSI/TIA/EIA-568-B.2 standards

PT # DCC2488/25V01

Call For Pricing

24 Port CAT 5e Patch Panels $38.99 each! (Pricing for 15 or more panels)

Part Number-ATDBL102203-C5e 24Port CAT 5e Patch Panel BEST PRICED PATCH PANEL IN THE USA!! UL LISTED- EIA-TIA-TESTED AND VERIFIED COMPLIANT TO EXCEED ATT CAT 5E SPECIFICATIONS - * Operating temperature : -40 to +70 dgree Celsius
* Weight : 1.65LBS
* Mounting Hinge: 102215
* 25 year warranty

* UL approved
* Meets TIA/EIA-568B.2/568B.2-1 Cat.5E
ISO/IEC 11801 and EN 50173-1 specification
* Support T568A & B wiring
* Wire diameter : 22 ~ 26AWG
* Insulation diameter range : 0.70 to 1.40mm
* Jack contacts : Phosphor bronze, 50micron gold plate over nickel plating.
* IDC contacts : Phosphor bronze, 50micron gold plate over nickel plating.
* Safty : UL1863
* Flamability : UL 94 VO

ATDBL102203-C5e

24 Port CAT 5e Patch Panels $38.99 each!

PT #ICMPP0485E -- black- ICC 48 Port CAT 5e Patch Panel PATCH PANEL, CAT 5E, 48-PORT- 2 RMS 48-Port CAT 5e Patch PanelExceeds TIA/EIA CAT 5e standards. Includes mounting screws.

Part Number ICMPP0485E

Price $149.29ea

PT # 48458MD-C5E-Signamax 48-Port Category 5e+ Patch Panel T568A/B Wiring Category 5e+ patch panels are designed to exceed TIA/EIA-568-B.2 component, permanent link and channel level performance specifications providing usable bandwidth beyond 155 MHz. These high-density panels are available in 12 through 96 port versions and feature enhanced front and rear labeling features for easy circuit identification. Category 5e+ panels support both T568A and T568B wiring configurations using an easy to read color-coded wiring label. 48458MD-C5E

Click Here For Pricing

Part Number: OR-PSD5E6U48
Clarity5E 48-Port Patch Panel is component compliant to EIA/TIA Category 5e performance requirements. Standard density design provides additional space for cabling and occupies three rack units, measuring 19" x 5.25". Jacks are grouped in six-port modules. Part of the Clarity5E link and channel solution that provides significant installed performance headroom

Part Number: OR-PSD5E6U48

Call For Pricing

PT # DCC2488/25V01-Superior Superior: Cat 5e Patch Panels • Black exterior • High density profile write-on port labels and 110 style connecting blocks for rear termination • Patented technology. • Comfortably exceeds all EIA/TIA 568-A, Cat 5 & 5e specifications Compliant with ISO/IEC11801 and ANSI/TIA/EIA-568-B.2 standards Call For Pricing
LE-5G596-U48- Leviton 48 Port CAT 5e Patch Panel- GigaMax 5e Universal 48-port Patch Panel, CAT 5e, 3.5"H x19"W, black
  • Meets or exceeds Category 5e requirements in TIA/EIA-568-B and Class E requirements in ISO/IEC 11801-B
  • Easy to install
  • Connector modules are grouped in sets of six
  • Panels contain both Universal T568A and T568B Wiring Configurations White IDC 110 punch down modules
  • Color-coded front window labeling

PT #LE-5G596-U48

Price $228.99ea

Full Power To Every Port
POWERTRAC delivers up to 48 ports (up to 2 full panels) of sustained full 802.3af power backed by each chassis style redundant power supply source. Independent power for PoE, asset management and control logic assures continuous security and administration
.
Call For Pricing
PT # P5E48UE P5E48UE- Hubbell 48 Port CAT 5e Patch Panel-

SPEEDGAIN® 5e series patch panels offer the most rugged, feature rich, and high performance Category 5e panels in the industry. SPEEDGAIN® panels significantly exceed Category 5e requirements with component and channel performance to 190MHz with enhanced warranty protection.

PT # P5E48UE



Call For Pricing






Call For Pricing at (866) 650-DATA
